Raivis Edition eCOM

Description

Raivis Edition eCOM is specifically designed for driving style of the master himself. Small footprint and rolling behavior is ideal for top drivers who are fighting for every centimeter in the race.

Specs

• 4 copper power layers
• Dimensions 18.5x23.5mm (0.73x0.93in)
• Supports 6 pole motors up to 36000KV* and 12 pole motors up to 18000KV*
• Startup at 2V
• Single-sided components

• Acrylic coating
• Reverse polarity protection
• Max operating voltage 15V


*Capabilities for Advanced timing version. Regular and Soft up to 32000KV for 6 pole and 16000KV for 12 pole motors.

Timing options

2°   Most aggressive timing

10° A little less aggressive than 2°, ideal for Eurosport

20° Slightly more aggressive than 30° (soft), also fits Eurosport for more technical tracks

30° The softest timing, ideal for F1

This is not an auto-brake eCOM!

Read more about Auto-Brake vs Standard eCOMs here

DO NOT clean with acetone or IPA!
